SPECIFICHE
Audio Performance
Output Signal-to-Noise Ratio (A-Weighted) (Front-out) : 105 dB
Input Signal-to-Noise Ratio (A-Weighted) : 103 dB
Output THD+N at 1kHz (Front-out) : <0.0025 %(-92 dB)
Input THD+N at 1kHz : <0.0022 %(-93 dB)
Frequency Response (-3dB, 24bit/96KHz input) : 10 Hz to 48 KHz
Bus Compatibility
PCI
Chipset
Audio Processor : C-Media CMI8786 High-Definition Sound Processor (Max. 96KHz/24bit)
Sample Rate and Resolution
Analog Playback Sample Rate and Resolution : 44.1K/48K/96KHz @ 16bit/24bit
Analog Recording Sample Rate and Resolution : 44.1K/48K/96KHz @ 16bit/24bit
S/PDIF Digital Output : 44.1K/48K/96KHz @ 16bit/24bit
I/O Ports
Analog Output Jack : 3 x 3.5mm RCA jack
Analog Input Jack : 1 x 3.5mm RCA jack
1 x Digital S/PDIF Output : 1 x Front-Panel Header
Other line-level analog input (for CD-IN/TV Tuner) : 4-pin header on the card
Special Features
Smart Volume Normalizer™
Xear 3D™ Virtual Speaker Shifter
Magic Voice™
Karaoke Functions
FlexBass™
10 -band Equalizer
27 Environment Effects
GX2.5 Gaming Audio Engine
VocalFX™
Accessories
Low -profile Bracket x 1
Driver CD x 1
Quick Start Guide x 1
Dimensions
170.4 x 64.34 mm ( L x W )
