SPECIFICHE
APU
FM1 Socket: 1.AMD A series & E2 series processors
Chipset
AMD A75 chipset
Memoria
4 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory
Dual channel memory architecture
Support for DDR3 2400(OC)/1866/1600/1333/1066 MHz memory modules
* The 1866 MHz memory speed is supported only when one or two DDR3 1866 MHz DIMMs are installed. It is not supported when four DIMMs are installed. (Dual channel memory mode must be enabled when installing two DIMMs.)
Grafica integrata
Integrated in the APU: 1.1 x DVI-D port, supporting a maximum resolution of 2560x1600
1 x HDMI port, supporting a maximum resolution of 1920x1200
1 x D-Sub port
*The resolution of 2560x1600 is supported only when Dual Link DVI mode is enabled.
(All integrated graphics ports do not support Hot plug. If you want to change to another graphics port when the computer is on, be sure to turn off the computer first.)
* The DVI-D port does not support D-Sub connection by adapter.
Audio
Support for Dolby Home Theater
Support for S/PDIF Out
2/4/5.1/7.1-channel
Realtek ALC889 codec
High Definition Audio
LAN
1 x Realtek 8111E chip (10/100/1000 Mbit)
Slot di Espansione
1 x PCI Express x16 slot, running at x16 (PCIEX16)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
2 x PCI Express x1 slots
(All PCI Express slots conform to PCI Express 2.0 Standard.)
3 x PCI
Multi Graphics Technology
Support for AMD CrossFireX technology
Support for AMD Dual Graphics technology
Only A series APU support AMD Dual Graphics.
Storage Interface
Chipset: 1.1 x eSATA 6Gb/s port on the back panel supporting up to 1 SATA 6Gb/s device
* Actual transfer rate is dependent on the device being connected.
5 x SATA 6Gb/s connectors supporting up to 5 SATA 6Gb/s devices
Support for RAID 0, RAID 1, RAID 10, and JBOD
USB
Chipset:
1.Up to 10 USB 2.0/1.1 ports (2 ports on the back panel, 8 ports available through the internal USB headers)
2.Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
Etron EJ168 chip:
1.Up to 2 USB 3.0/2.0 ports on the back panel.
Connettori Interni I/O
1 x APU fan header
1 x serial port header
1 x USB 3.0/2.0 header
1 x front panel audio header
1 x 24-pin ATX main power connector
5 x SATA 6Gb/s
1 x front panel header
1 x clearing CMOS jumper
2 x system fan headers
4 x USB 2.0/1.1
1 x 8-pin ATX 12V power connector
1 x power fan connector
1 x Trusted Platform Module (TPM) header
TPM function is optional due to different regional policy
1 x SPDIF out
Pannello Posteriore I/O
4 x USB 3.0/2.0 ports
1 x PS/2 keyboard/mouse port
1 x eSATA 6Gb/s
1 x DVI-D
1 x HDMI port
1 x D-Sub
1 x SPDIF out (optical)
6 x audio ports (Line In / Line Out / MIC In / Surround Speaker Out(Rear Speaker Out) / Center/Subwoofer Speaker Out / Side Speaker Out)
2 x USB 2.0/1.1
1 x RJ45 LAN
I/O Controller
iTE IT8720
Monitoraggio H/W
APU/System/Power fan fail warning
APU/System/Power fan speed detection
APU/System fan speed control
Whether the APU/system fan speed control function is supported will depend on the APU/system cooler you install.
APU overheating warning
APU/System temperature detection
System voltage detection
BIOS
2 x 32 Mbit flash
Use of licensed AWARD BIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Supports DualBIOS™
Altre Caratteristiche
Supports @BIOS™
Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
Support for ON/OFF Charge
Auto Green
Smart Recovery
Support for Q-Share
Supports Q-Flash utility
Xpress™ BIOS Rescue
Xpress™ Recovery 2
Xpress™ Install
Download Center
Support for 3TB+ Unlock
Software in Bundle
Norton Internet Security (OEM version)
Sistema Operativo
Microsoft® Windows® 7/ Vista/ XP
Caratteristiche Fisiche
ATX Form Factor; 305mm x 225mm
