SPECIFICHE
Power supply type
Metatron Series
ATX standard
ATX V2.3
Connectors
20+4 pin mainboard 1x 55cm
4+4 pin mainboard 12V (8 pin EPS) 1x 55cm
8 pin EPS mainboard 12V 1x 55cm
PCI-Express 3x PCI-Express 6 pin 65cm; 3x PCI-Express 6+2 pin 55cm
SATA 12 (3x 50 / 3x 65 / 3x 80 / 3x 95cm)
PATA 4 (1x 50 / 1x 65 / 1x 80 / 1x 95cm)
FDD 1x 110cm
Mark of conformity
CE / TÜV
Fan
140mm
PFC
active
Dimension
h x w x d 86 x 150 x 165mm
Weight
3,528kg
Power rating
1000W
Performance
max. peak load 1100W
+3,3V 24A
+5V 30A
max. combined 150W
+12V1 36A
+12V2 36A
+12V3 36A
+12V4 36A
max. combined 83A / 996W
Efficiency up to 90,69%
Standby consumption <1W
Security circuitry
OCP, OVP, UVP, SCP, OPP
