SPECIFICHE
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wireless Signal Rates With Automatic Fallback
11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Frequency Range
2.4-2.4835GHz
Wireless Transmit Power (MAX)
20dBm(Max. EIRP)
Modulation Technology
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Receiver Sensitivity
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Hardware Specification
Interface
4 10/100M LAN Ports
1 10/100M WAN Port
Antenna
5dBi Detachable Omni Directional Antenna X 2
Power Supply Unit
Input: Localized to Country of Sale
Output: 9VDC / 0.6A Switching PSU
Operating temperature
0ˇăC~40ˇăC (32¨H~104¨H)
Storage temperature
-40ˇăC~70ˇăC (-40¨H~158¨H)
Relative humidity
10% ~ 90%, Non Condensation
Storage Humidity
5%~95% Non-Condensing
Dimensions
7.6 x 5.1 x 1.3 in.(192 x 130 x 33 mm)
