SPECIFICHE
CPU
AMD AM3/AM2+/AM2 ;Phenom™II /Athlon™II /Phenom™ / Athlon™ /Sempron™ Processors
AMD Cool 'n' Quiet™ Technology
Support 45nm CPU
Chipset AMD 785G/SB710
* This model does NOT support ACC function.
System Bus Up to 5200 MT/s for AM3 /AM2+ CPU with HyperTransport™ 3.0;
Up to 2000 / 1600 MT/s for AM2 CPU
Memory
4 x DIMM, Max. 16 GB, DDR2 1200(O.C.)/1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to AMD CPU limitation, DDR2 1200/1066 is supported by AM3/AM2+ CPU for one DIMM per channel only.
Expansion Slots
1 x PCIe 2.0 x16
2 x PCIe x1
1 x PCI 2.2
VGA
Integrated ATI Radeon™ HD 4200 GPU
- Supports HDMI™ Technology with max. resolution up to 1920 x 1200 (1080P)
- Supports Dual-link DVI with max. resolution up to 2560x1600 @60Hz
- Supports D-Sub with max. resolution up to 2560x1440 @75Hz for 16:9 format
- Hybrid CrossFireX™ Support
- Dual independent displays support with HDMI/DVI and D-Sub
- Supports Microsoft® DirectX 10.1, OpenGL 2.0, Pixel Shader 4.0
- Hardware Decode Acceleration for H.264, VC-1, and MPEG-2
- Maximum shared memory of 512MB
Storage
SB710 Chipset
1 x external SATA 3Gb/s ports
5 x SATA 3Gb/s ports Support RAID 0,1,10
1 x Ultra DMA 133/100/66 for up to 2 PATA devices
* Due to the Windows XP/ Vista limitation, the RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only.
LAN
Realtek 8112L Gigabit LAN controller featuring AI NET 2
Audio
Absolute Pitch Hi-Fi featuring ENVY HD
- 10-channel High Definition Audio
- DTS Surround Sensation UltraPC
- Lossless 192kHz/ 24-bit BD audio
- Supports Jack-Detection, Multi-streaming
- 2-ch Gold-plated RCA output at back I/O
- Optical S/PDIF out port at back I/O
IEEE 1394
JMicron® JMB381 for 2 x 1394a ports
USB
10 USB 2.0/1.1 ports (6 ports at mid-board, 4 ports at back panel)
ASUS Unique Features
ASUS HTPC Features
- ASUS Absolute Pitch Hi-Fi
- ASUS Home Theater Gate
- ASUS Tranquil Mode (for AM3/AM2+ CPU only)
ASUS Express Gate
ASUS Fanless Design: Soundwave Heat-sink
ASUS EZ DIY:
- ASUS Q-Connector
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
Overclocking Features
Precision Tweaker
- vCore: Adjustable CPU voltage at 0.0125V increment
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz up to 600MHz at 1MHz increment
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
- GPU tuning from 500MHz up to 1500MHz
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
Back Panel I/O Ports
1 x DVI
1 x D-Sub
1 x HDMI
1 x External SATA
1 x S/PDIF Out (Optical)
1 x IEEE 1394a
1 x LAN(RJ45) port
4 x USB 2.0/1.1
10 -Channel Audio I/O
2-ch RCA auido output connectors
Internal I/O
Connectors 3 x USB connectors (6 ports)
1 x IDE connector
5 x SATA connectors
1 x CPU Fan connector
2 x Chassis Fan connector
1 x Power Fan connector
Front panel audio connector
1 x S/PDIF out header
CD audio in
24-pin ATX Power connector
4-pin ATX 12V Power connector
4-pin ATX 12V Audio power connector
System Panel
BIOS
16 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0
Accessories
User's manual
1 x I/O Shield
1 x UltraDMA 133/100/66 cable
2 x SATA cable(s)
2 in 1 Q-connector (USB, System panel; Retail version only)
Support Disc
Drivers
Anti-virus software (OEM version)
ASUS Update
ASUS Utility
Form Factor
uATX Form Factor
24.4 cm x 24.4 cm
