SPECIFICHE
CPU
AMD Socket AM3 ;Phenom™II /Athlon™II /Sempron™ 100 Series Processors
AMD 140W CPU Support
AMD Cool 'n' Quiet™ Technology
Supports 45nm CPU
Chipset
AMD 870 / SB850
System Bus
Up to 5200 MT/s ; HyperTransport™ 3.0 interface
Memory
4 x DIMM, Max. 16 GB, DDR3 2000(O.C.)/1600/1333/1066 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
* DDR3 Memory Ultra Low Voltage support
**Due to CPU spec., AMD 100 and 200 series CPUs support up to DDR3 1066MHz. With ASUS design, this motherboard can support up to DDR3 1333MHz
Expansion Slots
1 x PCIe 2.0 x16
1 x PCIe 2.0 x4
1 x PCIe 2.0 x1
3 x PCI
Storage
SB850 Chipset
6 xSATA 6.0 Gb/s ports Support RAID 0,1,5,10
JMicron® JMB368 PATA controller
1 xUltraDMA 133/100 for up to 2 PATA devices
LAN
Realtek® 8111E Gigabit LAN controller featuring AI NET2
Audio
VIA VT1818 8-Channel High Definition Audio CODEC
- Supports 192kHz/ 24bit BD Lossless Sound
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
- Optical S/PDIF Out port at back I/O
- ASUS Noise Filter
USB
14 USB 2.0/1.1 ports (6 ports at mid-board, 8 ports at back panel)
ASUS Unique Features
ASUS Xtreme Design
ASUS Hybrid Processor -- TurboV EVO
- Turbo Unlocker, TurboV, Turbo Key, CPU Level UP
ASUS Hybrid Switch
- Core Unlocker
ASUS Hybrid OS -- Express Gate
ASUS Power Solutions
- ASUS EPU
ASUS Exclusive Features
- MemOK!
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Heat sink solution
- ASUS Fan Xpert
ASUS EZ DIY
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
- Multi-language BIOS
Overclocking Features
Precision Tweaker 2
- vCore: Adjustable CPU voltage at 0.003125V increment
- vDDNB: Adjustable CPU NB voltage at 0.003125V increment
- vNB: Adjustable North Bridge voltage at 0.00625V increment
- vHT bus: Adjustable PCH voltage at 0.00625V increment
- vDRAM Bus: Adjustable DRAM voltage at 0.00625V increment
SFS (Stepless Frequency Selection)
- Internal Base Clock tuning from 100MHz up to 600MHz at 1MHz increment
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
Back Panel
I/O Ports 1 x S/PDIF Out (Optical)
1 x LAN(RJ45) port
8 x USB 2.0/1.1
8 -Channel Audio I/O
1 x PS/2 Keyboard (Purple)
1 x PS/2 Mouse (Green)
Internal I/O Connectors
3 x USB connectors support additional 6 USB ports
1 x IDE connector
6 x SATA 6Gb/s connectors
1 x CPU Fan connector
1 x Chassis Fan connector (3-pin)
1 x Power Fan connector
1 x S/PDIF Out Header
1 x Core Unlocker Switch
1 x MemOK! Button
Front panel audio connector
1 x COM connector
1 x Clear CMOS jumper
24-pin ATX Power connector
4-pin ATX 12V Power connector
System Panel
BIOS
8 Mb Flash ROM , SPI, AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
Accessories
1 x Ultra DMA 133/100 cable
2 x Serial ATA 3.0Gb/s cables
1 x Serial ATA 6.0Gb/s cables
1 x IO Shield
2 in 1 Q-connector (USB, System panel; Retail version only)
User's manual
Support Disc
Drivers
Anti-virus software (OEM version)
ASUS Utilities
ASUS Update
Form Factor
ATX Form Factor 30.5 cm x 21.3 cm
