SPECIFICHE
Active Power Factor Correction (PFC) - internal
Input Voltage AC 120-240 V
Output Voltage +3.3, +5, ±12 V
Output connectors 4 pin internal power, 4 pin mini-power connector, 15 pin Serial ATA power, power 24 pin ATX with detachable 4 pin section, 8 pin PCI Express power with detachable 2 pin section, power 8 pin +12V with detachable 4 pin section
Power Output Connectors Details 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 4 x 8 pin PCI Express power with detachable 2 pin section ¦ 9 x 15 pin Serial ATA power ¦ 8 x 4 pin internal power ¦ 2 x 4 pin mini-power connector
Power Provided 650 Watt
Output Current +3.3V - 24 A ¦ +5V - 30 A ¦ +12V - 52 A ¦ -12V - 0.8 A ¦ +5VSB - 3 A
MTBF 100,000 hour(s)
Features Overcurrent protection, overvoltage protection, overpower protection, SLI ready, undervoltage protection, cable management, short-circuit protection
Compliant Standards FCC Class B certified, CE, UL, TUV, C-Tick, cUL, CB, CCC, 80 PLUS Bronze
