SPECIFICHE

CPU
Intel Socket 1366 Core™ i7 Processor Extreme Edition/Core™ i7 Processor Supports Intel® Dynamic Speed Technology

Chipset
X58 / ICH10R
Up to 6400 ; Intel® QuickPath Interconnection MT/s

Memoria
6 x DIMM, 24 GB, DDR3 1600(O.C.)/2000(O.C.)*/1866(O.C.)*/1800(O.C.)*/1333/1066 Non-ECC,Un-buffered Memory
Triple channel memory architecture
Supports Intel® Extreme Memory Profile (XMP)

Slot di Espansione
3 x PCIe 2.0 x16 (at x16/x16/x4 mode)
3 x PCIe x1 1
2 x PCI

Multi-GPU Support
Supports ATI® Quad-GPU CrossFireX™ Technology

Storage
6 xSATA 3 Gb/s ports
0,1,5,10 Intel Matrix Storage Technology supports Support RAID UltraDMA 133/100/66 for up to 2 PATA devices
1 x External SATA 3Gb/s port (SATA On-the-Go)
1 x JMicron® JMB363 PATA and SATA controller

LAN
Realtek® 8111C PCIe Gigabit LAN controller featuring AI NET2

Audio
Realtek® ALC1200 8 -Channel High Definition Audio CODEC
Support Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
Coaxial / Optical S/PDIF out ports at back I/O
ASUS Noise-Filtering

IEEE 1394
2 VIA® VT6315N controller supports x 1394a ports (one at mid-board; one at back panel)

USB
USB 2.0 ports (6 ports at mid-board, 6 ports at back panel) 12

ASUS AI Lifestyle
ASUS Exclusive Features:
- ASUS TurboV
- ASUS 8+2 Phase Power Design
- Express Gate
ASUS Power Saving Solution
- ASUS EPU-6 Engine
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Heat-pipe solution
- ASUS Fanless Design: Stack Cool 2
- ASUS Fan Xpert
ASUS Crystal Sound:
- ASUS Noise Filter
ASUS EZ DIY:
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2

Caratteristiche di Overclock
Precision Tweaker - vChipset (N.B.): 31-step chipset voltage control
- vCore: Adjustable CPU voltage at 0.0125V increment 0.00625V 2
SFS (Stepless Frequency Selection)
- Internal Base Clock tuning from 100MHz up to 500MHz at 1MHz increment
- PCI Express frequency tuning from 100MHz 180MHz at 1MHz
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

Caratteristiche Speciali
Multi-language BIOS
ASUS MyLogo 2

Porte I/O Pannello Posteriore
1 x PS/2 Keyboard (Purple)
1 x PS/2 mouse port (Green)
1 x Coaxial S/PDIF Output
1 x Optical S/PDIF Output x External SATA
1 x IEEE 1394a
1 x RJ45 port
6 x USB 2.0/1.1
8 Channel Audio I/O

Connettori I/O Interni
3 x USB connectors support additional 6 USB ports
3 CD audio in
24-pin ATX Power connector
1 x 8-pin ATX 12V Power connector
System Panel(Q-Connector)
1 x Power on switch
x IDE connector
1 x SATA connectors
6 x IEEE 1394a connector
1 x CPU Fan connector
1 x Chassis Fan connector
1 x S/PDIF Out connector
1 Front panel audio connector

BIOS
16 Mb Flash ROM
AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.3, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3

Gestibilità
WfM 2.0,DMI 2.0,WOL by PME,WOR by PME,WOR by PME

Accessori
User's manual
ASUS Q-Shield x UltraDMA 133/100/66 cable
1 x SATA cable
4 2 in 1 Q-connector

CD di Supporto
Drivers
Image-Editing Suite
ASUS PC Probe II
ASUS AI Suite
Anti-virus software (OEM version)
ASUS Update

Dimensioni
ATX Form Factor 30.5 cm x 24.4 cm
